2.5D Image Measurement Instrument

2.5D Image Measurement Instrument

*1
Optical Image measurement_2.png
/
DETAIL
 (Video Measuring System, VMS) This is currently the most common equipment in factories, also known as an "image projector." It combines a CCD camera and measurement software, allowing users to directly select points on a computer screen to measure line segments, circles, arcs, distances, etc.

Features: High precision, suitable for measuring delicate parts (such as mobile phone parts, connectors).

2.5D: Refers to the ability to measure vertical (Z-axis) height in addition to XY plane measurements by adjusting the lens focus.
